CNC Collet Types:

In the realm of CNC machining, collets play a vital role in securely holding and accurately positioning cutting tools. The selection of the right collet type is crucial for achieving precise and efficient machining results. Ruihan offers a wide variety of CNC collet types.

1. ER Collets

ER collets, also known as Elastic Retention collets, are widely used in CNC machining. These collets utilize a compression mechanism to grip the tool tightly. They feature a cylindrical body with multiple slits that provide elasticity, allowing the collet to expand and contract to accommodate different tool diameters. ER collets are renowned for their exceptional gripping power, concentricity, and versatility. They are suitable for a wide range of cutting tools, including drills, end mills, reamers, and taps.

2. OZ Collets

OZ collets, also called OZ25 and OZ32 collets, are commonly used in CNC routers and machining centers. These collets feature a unique design with a hexagonal shape and a threaded nut for tool clamping. OZ collets offer excellent concentricity and are specifically designed for high-speed machining applications. They provide reliable gripping power and are often used with router bits, engraving tools, and other similar cutting tools.

3. R8 Collets

R8 collets are widely used in milling machines, especially in the context of manual machining and Bridgeport-style mills. These collets have a taper of 7:24 and a threaded back that allows for quick and secure tool changes. R8 collets are known for their excellent gripping power and concentricity. They are compatible with R8 spindles and are commonly used with end mills, shell mills, and other milling cutters.

4. SK Collets

SK collets, also known as SK40 and SK50 collets, are popular in CNC machining centers. These collets feature a steep taper design, ensuring strong and rigid tool clamping. SK collets provide excellent runout accuracy and are suitable for heavy-duty machining operations. They are commonly used with solid carbide end mills, drills, and other cutting tools.

5. BT Collets

BT collets, short for BT30 and BT40 collets, are widely used in CNC milling machines. These collets have a taper design similar to SK collets but with a different flange configuration. BT collets provide high clamping forces, ensuring reliable tool holding during heavy-duty machining. They are compatible with BT spindles and are commonly used with end mills, drills, and tapping tools.

6. HSK Collets

HSK collets, also known as HSK63 and HSK100 collets, are widely used in high-speed machining applications. These collets feature a hollow shank taper design that allows for efficient coolant flow. HSK collets provide exceptional rigidity, runout accuracy, and tool stability. They are commonly used with high-performance cutting tools, such as high-speed end mills and drills.

Choosing the right CNC collet type is essential for achieving precise and efficient machining results. Whether you require versatility, gripping power, concentricity, or specialized features for high-speed or heavy-duty applications, there is a collet type available to meet your needs. Consider the specific requirements of your machining project, including the type of cutting tools, spindle compatibility, and machining application, to make an informed decision. By selecting the appropriate collet type, you can enhance the performance of your CNC machining operations and achieve superior results.

Get in touch now!

Precision R8 Collet Inquire Now

ER Tap Collet Inquire Now

Morse Taper Collet Inquire Now

OZ Collet B Type Inquire Now

ER Rubber Sealed Collet Inquire Now

DIN6499B Standard ER collet Inquire Now

OZ Collet (A) Inquire Now

Precision 5C Hex Collet Inquire Now

Previous 1 2 Next

Select

ER Collets vs TG Collets:

When it comes to precision machining, the choice of collet can significantly impact the quality and efficiency of your work. Two popular collet types often compared are ER collets and TG collets.

ER Collets:

ER collets, also known as Elastic Retention collets, are widely used in the machining industry. These collets feature a cylindrical body with slits that provide elasticity, allowing them to expand and contract to accommodate different tool sizes. ER collets offer superior gripping power, excellent concentricity, and a wide range of sizes, making them suitable for various machining applications.

TG Collets:

TG collets, short for Tool Grip collets, are another popular choice in precision machining. Unlike ER collets, TG collets use a collet chuck with an internal taper and a threaded nut to secure the tool. These collets offer excellent holding power, high rigidity, and precise concentricity, making them suitable for demanding machining operations.

Comparison: ER Collets vs TG Collets

Let's compare ER collets and TG collets in various aspects to understand their similarities and differences.

1. Grip Mechanism

ER Collets: ER collets utilize a compression mechanism to grip the tool. The slits on the collet body provide elasticity, allowing for tool insertion and secure gripping.

TG Collets: TG collets use an internal taper and a threaded nut to grip the tool. The collet chuck applies axial force to secure the tool tightly.

2. Gripping Power

ER Collets: ER collets offer excellent gripping power, preventing tool slippage during machining operations. They are particularly effective for light to medium-duty applications.

TG Collets: TG collets provide exceptional holding power, making them suitable for heavy-duty machining where higher clamping forces are required.

3. Concentricity

ER Collets: ER collets exhibit exceptional concentricity, minimizing tool runout and ensuring precise machining.

TG Collets: TG collets are known for their precise concentricity, delivering accurate and repeatable machining results.

4. Tool Sizes

ER Collets: ER collets come in a wide range of sizes, accommodating various tool diameters. From ER8 to ER50, there are different collet sizes available to match specific tool requirements.

TG Collets: TG collets are available in different sizes, typically designated as TG75, TG100, and TG150, corresponding to different tool diameters.

5. Versatility

ER Collets: ER collets are compatible with a wide range of cutting tools, including drills, end mills, reamers, and taps. They offer versatility in tool selection.

TG Collets: TG collets are primarily used with solid carbide tools and are ideal for high-performance machining applications.

6. Applications

ER Collets: ER collets find applications in various machining operations, including milling, turning, reaming, thread cutting, engraving, and deburring.

TG Collets: TG collets are commonly used in high-precision machining applications that require exceptional rigidity and accuracy, such as aerospace and medical device manufacturing.

Conclusion

Both ER collets and TG collets are reliable choices for precision machining, each with its own advantages and applications. ER collets offer a wide range of sizes, excellent gripping power, and versatility, making them suitable for a broad range of machining needs. On the other hand, TG collets provide exceptional holding power, rigidity, and precise concentricity, making them ideal for demanding machining operations. Understanding the specific requirements of your machining project will help you determine whether ER collets or TG collets are the right choice for you.
