HSK63A End Mill Holders
Material:20CrMnTi
Hardness:HRC52-58
Runout :G2.5 30000rpm balanced
HSK63A End Mill Holders
| Order No. HSK.AXd-L1 | L | L2 | L3 | L4 | D | d1 | T |
| HSK50AX6-65 | 90 | 39 | 18 | — | 50 | 25 | M6X1.0 |
| HSK50AX8-65 | 90 | 39 | 18 | — | 50 | 28 | M8X1.25 |
| HSK50AX10-65 | 90 | 39 | 20 | — | 50 | 35 | M10X1.5 |
| HSK50AX12-80 | 105 | 54 | 22.5 | — | 50 | 42 | M12X1.75 |
| HSK50AX14-80 | 105 | 54 | 22.5 | — | 50 | 44 | M12X1.75 |
| HSK50AX16-80 | 105 | 54 | 24 | — | 50 | 48 | M14X2.0 |
| HSK50AX18-80 | 105 | 54 | 24 | — | 50 | 50 | M14X2.0 |
| HSK50AX20-80 | 105 | 54 | 25 | — | 50 | 52 | M16X2.0 |
| HSK63AX6-65 | 97 | 39 | 18 | — | 63 | 25 | M6X1.0 |
| HSK63AX8-65 | 97 | 39 | 18 | — | 63 | 28 | M8X1.25 |
| HSK63AX10-65 | 97 | 39 | 20 | — | 63 | 35 | M10X1.5 |
| HSK63AX12-80 | 112 | 54 | 22.5 | — | 63 | 42 | M12X1.75 |
| HSK63AX14-80 | 112 | 54 | 22.5 | — | 63 | 44 | M12X1.75 |
| HSK63AX16-80 | 112 | 54 | 24 | — | 63 | 48 | M14X2.0 |
| HSK63AX18-80 | 112 | 54 | 24 | — | 63 | 50 | M14X2.0 |
| HSK63AX20-80 | 112 | 54 | 25 | — | 63 | 52 | M16X2.0 |
| HSK63AX25-110 | 142 | 84 | 24 | 25 | 63 | 65 | M18X2.0 |
| HSK63AX32-110 | 142 | 84 | 24 | 28 | 63 | 72 | M20X2.0 |
| HSK100AX6-80 | 130 | 51 | 18 | — | 100 | 25 | M6X1.0 |
| HSK100AX8-80 | 130 | 51 | 18 | — | 100 | 28 | M8X1.25 |
| HSK100AX10-80 | 130 | 51 | 20 | — | 100 | 35 | M10X1.5 |
| HSK100AX12-80 | 130 | 51 | 22.5 | — | 100 | 42 | M12X1.75 |
| HSK100AX14-80 | 130 | 51 | 22.5 | — | 100 | 44 | M12X1.75 |
| HSK100AX16-100 | 150 | 71 | 24 | — | 100 | 48 | M14X2.0 |
| HSK100AX18-100 | 150 | 71 | 24 | — | 100 | 50 | M14X2.0 |
| HSK100AX20-100 | 150 | 71 | 25 | — | 100 | 52 | M16X2.0 |
| HSK100AX25-100 | 150 | 71 | 24 | 25 | 100 | 65 | M18X2.0 |
| HSK100AX32-100 | 150 | 71 | 24 | 28 | 100 | 72 | M20X2.0 |
| HSK100AX40-100 | 150 | 71 | 30 | 32 | 100 | 90 | M20X2.0 |
